VPIlinkDesigner™ – New version 4.4 released!

VPIphotonics announces the release of VPIlinkDesigner Version 4.4, a software tool for optical link engineering including automated equipment placement and configuration and a thorough system wide performance assessment. It supports equipment configuration and detailed performance calculation of complex networks including ROADMs and true ring topologies.

Version 4.4 improves the network design workflow and provides functionality that supports multi-band DWDM transmission technologies including high bit rate transceivers with advanced modulation formats along with flex-grid wavelength assignment. The new built-in functionality simplifies and accelerates the design process. With the improved capabilities provided in version 4.4, VPIlinkDesigner continuously supports its existing and addresses new applications.

Among the new features of version 4.4 are

  • Design Assistant – updated Summary Table to report broken connections along with violations of equipment limits and design constraints.


Design Assistant mode
Design Assistant mode

  • Add/Drop Equipment Configuration – enhanced Setup Node Equipment tool to allocate add/drop equipment for several nodes or the whole network simultaneously.

  • Multi-band DWDM signal and Flex-grid – simulation engine was enhanced with respect to simulation time and memory utilization.

  • Equalization Mode – an improved version of WSS ROADM model to account for an Optical Channel bandwidth that can significantly differ from the symbol rate for several advanced modulation formats.


  • Traffic Demand Routing Algorithms – a new routing algorithm to account for the OSNR degradation due to amplifier noise. The existing routing algorithms have been significantly accelerated.

  • Simplified Equipment Library Management – to update system requirements parameters automatically when new network design is started or to select the required library easily when an existing network design is updated.
