  • Black Box Model vs. EDFA for 1480nm Pumping
    Explicit Pump Power Dependence


    Demonstrates the modeling of EDFAs with explicit dependence on 1480-nm pump power by applying an EDFA Black Box model.

    Picture for Black Box Model vs. EDFA for 1480nm Pumping<br>Explicit Pump Power Dependence

    » Keywords: Optical amplifier, EDFA, Pump power dependence, , Black-box model
    » Available in: Fiber Optics Demos

  • Concentration Quenching in
    Erbium-doped Fiber Amplifiers


    Demonstrates the effect on amplifier performance of concentration quenching that results from upconversion and pair-induced quenching.

    Picture for Concentration Quenching in<br>Erbium-doped Fiber Amplifiers

    » Keywords: Concentration quenching, Upconversion, Example, DopedFiber
    » Available in: Fiber Optics Demos

  • Gain Ripple in Erbium-doped Fiber Amplifiers
    due to Spectral Hole Burning (SHB)


    Demonstrates gain ripple in Erbium-Doped Fiber Amplifiers due to Spectral Hole Burning (SHB). Requires both VPItransmissionMaker Optical Systems and VPIcomponentMaker Fiber Optics profiles.

    Picture for Gain Ripple in Erbium-doped Fiber Amplifiers <br>due to Spectral Hole Burning (SHB)

    » Keywords: SHB, Example, DopedFiber
    » Available in: Fiber Optics Demos
